Relatech CXS SNMP Device Integration

The Relatech CXS SNMP DA Server provides access to network attached devices through the standardized SNMP protocol.

The CXS SNMP Device Integration comes with these options:

• Integrated into Ignition

• As a stand alone OPC 2.05 DA Server

• With an additional CXS SNMP Explorer for advanced discovery features

Features and Benefits

Integrated Discovery

The integrated SNMP browser in the DI objects provides direct access to standard and vendor specific data points.

SNMP V1, V2 and V3 Support

The CXS SNMP DA Server supports SNMP versions 1, 2 and 3. SNMP V3 security and authentication is fully supported

SNMP Traps Support

Configure and receive SNMP traps to monitor network exception conditions.

CXS Datacenter extensions

Use the CXS SNMP Explorer Datacenter extensions to create rack PDU profiles and add new server racks without any development effort.

Integrated export/ import feature

Import/ export mechanism enables the user to manage MIB file sets within on single file.

All in one integration of Application and DI Object

Intelligent DI object reduce the complexity of your application while enhancing functionality.

Summary

SNMP versions 1, 2 & 3 support

SNMP Traps support

Supports Ignition

Supports the use of Management Information Base (MIBs) files

Generic and extended OID referencing syntax

Easy configuration of OID items to Ignition attributes including properties and data type handling

Automatic Ignition attribute generation
